Proteus Professional is a Shareware software in the category Education developed by Labcenter Electronics. In summary, Proteus 7.0 is the program to use when you want to simulate the interaction between software running on a microcontroller and any analog or digital electronic device connected to it. Proteus VSM comes with extensive debugging features, including breakpoints, single stepping and variable display for a neat design prior to hardware prototyping. One of the main components of Proteus 7.0 is the Circuit Simulation - a product that uses a SPICE3f5 analogue simulator kernel combined with an event-driven digital simulator that allow users to utilize any SPICE model by any manufacturer. This program allows users to interact with the design using on-screen indicators and/or LED and LCD displays and, if attached to the PC, switches and buttons. This is the perfect tool for engineers to test their microcontroller designs before constructing a physical prototype in real time. it is possible to save templates in various formats.Proteus is a Virtual System Modelling (VSM) that combines circuit simulation, animated components and microprocessor models to co-simulate the complete microcontroller based designs.you can edit, simulate and verify schematics.allows you to design printed circuit boards.compatible with modern Windows versions.Alternatively, you may use such tools as PCB Artist or PCB Wizard. In addition, you have the option to edit and save templates in different formats. It is also possible to perform debugging of the entire project. Graphs that are provided in the design may be edited, simulated, verified and exported. In this tab, you can make modifications at the most basic level for each element of the loaded project. Additional functionsīesides the schematic capture mode that allows you to see all the devices and their connections, there is another feature called Source Code. You also have the ability to customize each item and there are several viewing options you may try to streamline your workflow. The application enables you to launch interactive simulations, as well as view and edit the properties of every element on the board. By doing so, you are able to view exactly what the utility is used for and how detailed is the perspective insofar as the schema design is concernced. The best way to get started is to load one of the many preset samples. However, it is necessary to mention that the software is meant for advanced users who have a good grasp on the mechanics involved. It features an intuitive graphical interface, which provides all the necessary instruments and commands for creating and testing PCB designs.
Proteus is a powerful program for Windows developed in order to assist users in building and verifying the circuit boards.
